Feeding Way

coil label or single card

Printing Speed

600dpi*200dpi-1200dpi stepless adjustable, print speed 38-240 m/min adjustable.

Software

Support text, Numbers, English, bar code, electronic supervision code, security code, etc.

Suitable Printing Material

Various types of paper including: adhesive, PE, PET, HDPE, PET, PVC ,etc.

Printing Color

Monochrome, Customized color,

Curing Way

curing by LED UV

Platform Driven

Full servo control

Print Specifications

RICOH GEN5

RICOH GEN6

Drop Volume

7-21PL, 4 level grayscale adjustable

5-15PL，8 level grayscale adjustable

Printing Length

54.1mm extensible

54.1 mm extensible

Printhead Type

Industrial - grade piezoelectric nozzle

Industrial - grade piezoelectric nozzle

Ink Type

UV inks

UV、Water-based, Solvent-based

Ignition Frequency

30KHZ

50KHZ

Printing Resolution

Horizontal is 600dPI fixed, longitudinal is 200-1200dpi adjustment

Horizontal is 600dPI fixed, longitudinal is 200-1200dpi adjustment
